Laminar Air Flow Horizontal
Price range: ₹125,000.00 through ₹178,000.00
Horizontal Laminar Air Flow (LAF) creates a particle-free, sterile work zone by pulling air through a HEPA filter at the back of a cabinet and directing it in a smooth, parallel stream horizontally toward the user, protecting the sample/product, not the operator. It’s used for contamination-sensitive tasks in labs (microbiology, electronics assembly) where a clean, unidirectional airflow sweeps contaminants away from the work surface.
Description
Horizontal Laminar Air Flow (HLAF):
A horizontal laminar air flow (HLAF) cabinet is a sterile workbench that uses a HEPA-filtered air stream moving horizontally from the back toward the operator. It creates an ISO Class 5 (Class 100) environment to protect samples and products from contamination during non-hazardous tasks like tissue culture, electronics assembly, or electronics inspections.
| Make | EASELAB | ||
| Model | ELLAF-001 | ELLAF-002 | ELLAF-003 |
| Size | 3*2*2 | 4*2*2 | 6*2*2 |
| Material | Main Body: Cold rolled steel with anti bacteria powder coating, work table SS-304 | ||
| Windows | Acrylic sheet | ||
| Pre filter HEPA Filter | Polyester fiber, washable, 99.999% efficiency at 0.3 µm | ||
| Noise | <65dB (A) | ||
| UV Lamp | 20W | 20W | 30W |
| Work surface height | 750mm | ||
| Display | LCD | ||
| Airflow velocity | Average of 0.3~0.5 m/s | ||
| Power Supply | AC220V+10%, 50/60 Hz. | ||
Standard Accessories: LED Lamp, UV Lamp, Base Stand, Water tap, waterproof socket.
Optional Accessories: Electric height adjust base stand.
Additional information
| SIZE | 3*2*2, 4*2*2, 6*2*2 |
|---|
